Basic Feature:
H.264 compression, Real time 4/8/16 Channel
Support Network(RJ45),IE browsing,3G mobile,Phone Surveillance And E-mail
Support 1 RS485 and 1 VGA
Support motion detection,Mouse,Remote control
Support Automatically Save date after powering off
Support 17 Language(Polish, Russian,Spanish, Portuguese,Dutch,Hungarian,Danish,Greek,Czech,Korean, Thai,Vietnamese,Bahasa,French, Italian, Turkish, English, Chinese)
Support 3G mobile View(Mobile phone monitoring: Iphone,Blackberry,Android,Windows mobile,Symbian.
Specification:
|
Models |
CW-6504 |
CW-6508 |
CW-6516 |
|
|
System |
User Interface |
Graphic User interface(OSD Menu) |
||
|
Video |
Video input |
4 channels |
8 channels |
16 channels |
|
Video output |
1 video output |
1 video output |
||
|
Display |
1/4 optional |
1/4/9 optional |
1/4/9/16 optional |
|
|
Video standard |
PAL 25f/s CCIR625; NTSC 30 f/s CCIR525 |
|||
|
Audio |
Audio input/output |
4 input, 1 output |
8 input, 1 output |
16 input, 1 output |
|
Audio compress |
ADPCM |
|||
|
Image & storage |
video compress |
H.264 VBR/CBR |
||
|
Image quality |
CIF/HD1/D1 (optional) |
|||
|
resolution |
4 Channel D1 |
4 ch D1 + 4 ch CIF |
4 ch D1 + 12 ch CIF |
|
|
Video Bit Rate |
CIF: 384~768 Kbps (Optional) |
|||
|
HD1: 512~1024 Kbps(Optional) |
||||
|
D1: 512~1024 Kbps (Optional) |
||||
|
Audio Bit Rate |
32Kbps |
|||
|
Storage |
2 SATA HDD |
2 SATA HDD |
||
|
Alarm |
Alarm in |
4 Alarm in |
8 Alarm in |
16 Alarm in |
|
Alarm output |
1 Alarm output |
1 Alarm output |
4 Alarm output |
|
|
Others |
Serial |
RS485 |
||
|
Lan |
1 RJ4510M/100M |
|||
|
VGA |
VGA output |
1024*768@60fps, 1280*720@60fps, 1280*1024@60fps, 1400*900@60fps, 1366*768@60fps |
||
|
Operation temperature |
-10℃~60℃ |
|||
|
Operation humidity |
10%~90% |
|||
|
Power input |
DC: 12V@3A |
|||
|
Power consumption |
6W(without HDD & other) |
|||
|
Dimensionmm |
495L*405W*108H (mm) |
495L*405W*108H (mm) |
||
|
Weights |
6KG |
6.5KG |
||
