Key Features:
• Up to 25/32 channel with 1080p realtime live view
• H.264/MJPEG decoding & H.264 dual-stream encoding
• IP: Max 9/16CH 1080P;Analog: 16CH D1 realtime recording
• HDMI / VGA / TV / Spot simultaneous video output
• All channel synchronous realtime playback, GRID interface & smart search
• Support P2P function to do remote viewing through computer and mobile phone
• Support ONVIF
• Auto IP address acquisition by IP Search function
• Support 8 SATA HDDs up to 24TB, 1 eSATA up to 16TB, 4 USB2.0
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Specification:
|
Model |
CW-HVR25A |
CW-HVR32A |
|
System |
||
|
Main Processor |
Dual-core embedded processor |
|
|
Operating System |
Embedded LINUX |
|
|
Video |
||
|
IP Video Input |
9 channel |
16 channel |
|
Analog Video Input |
16 channel, BNC |
16 channel, BNC |
|
Analog Video Standard |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
|
|
Loop Output |
8 channel, BNC |
16 channel, BNC |
|
Audio |
||
|
Input |
16 channel |
16 channel |
|
Output |
1 channel |
|
|
Two-way Talk |
1 channel Input, 1 channel Output |
|
|
Display |
||
|
Interface |
1 HDMI, 1 VGA, 1 TV, 1 Spot, BNC |
|
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
|
Display Split |
1/4/8/9/16/25 |
1/4/8/9/16/25/32 |
|
Privacy Masking |
4 rectangular zones (each camera) |
|
|
OSD |
Camera title, Time, Video loss, Camera lock, Recording |
|
|
Recording |
||
|
Video/Audio Compression |
H.264 / MJPEG(IP) / G.711 |
|
|
Resolution |
1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480) |
|
|
Record Rate |
IP : Max 1080P(25/30fps) |
|
|
Analog: Max D1(25/30fps) |
||
|
Bit Rate |
IP: 48~8192 Kb/s, Analog: 48~4096Kb/s |
|
|
Record Mode |
Manual, Schedule(Regular(Continuous), Alarm), Stop |
|
|
Record Interval |
1~120 min. (default: 60 min.), Pre-record: 1~30 sec., Post-record: 10~300 sec. |
|
|
Video Detection & Alarm |
||
|
Trigger Event |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips |
|
|
Alarm Input |
16 channel |
16 channel |
|
Relay Output |
4 channel |
|
|
Playback & Backup |
||
|
Sync Playback |
1/4/9/16 |
1/4/9/16 |
|
Search Mode |
Time/Date, Alarm, Exact search (accurate to second), Smart search |
|
|
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
|
Backup Mode |
USB Device / eSATA Device / Internal SATA burner/ Network |
|
|
Network |
||
|
Ethernet |
RJ-45 port (10/100M/1000M) |
|
|
Network Function |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
|
|
Max. User Access |
20 users |
|
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
|
Storage |
||
|
Internal HDD |
8 SATA ports up to 24TB |
|
|
External HDD |
1 eSATA port (Max 4 SATA HDDs), up to 16TB |
|
|
Auxiliary Interface |
||
|
USB |
2 ports (1 Rear), USB2.0 |
|
|
RS232 |
1 port, For PC communication & Keyboard |
|
|
RS485 |
1 port, For PTZ control |
|
|
General |
||
|
Power Supply |
AC 100~240V, 50/60 Hz |
|
|
Power Consumption |
30W |
40W |
|
Working Environment |
-10 ~+55°C / 10~90%RH / 86~106kpa |
|
|
Dimension |
2U, 440mm×460mm×89mm |
|
|
Weight |
9.5KG(without HDD) |
|
