Basic Feature:
Use H264 compresion algorithm.
Maximum output resolution of HDMI and VGA can be up to1280*1024.
Support HDMI,VGA and CVBS output synchronously.
Support voice intercorm.
Support electronic zoom in preview and playback.
Support pinyin input system.
Support one key to run recording.
Support multiple PTZ control protocols.
Support search, playback, backup the recording according to events.
Support recording and playback synchronously in 16ch D1.
Support 8 SATA ports to get 24TB
Built-in DDNS such as 3322.org,dyndns.com,oray.net,and buit-in ARSP "xmsecu.com".
Support NTP（Internet timing）, DHCP（Automatically get IP),Email(Mail Service),UPNP（Universal Plug and Play）,IP Filter(Permissions Set);FTP(Network Upload)
Specification：
|
System |
Main processor |
High performance embedded microprocessor / Hi3520*2 |
|
Operating system |
Embedded LINUX operating system |
|
|
Language |
English, Simplified Chinese , Traditional Chinese , Brazilian , Russian, Portuguese, Spanish , Italian , Korean , French , Czech , Hebrew , German , Finnish , Bulgarian , Swedish , Romanian , Greek, Etc. |
|
|
System resources |
Pentaplex function: Live, recording, playback, backup& remote access |
|
|
Control mode |
Front panel, USB mouse, Network, IR remote control |
|
|
Video |
Input |
16CH, BNC(1.0Vp-p, 75Ω) |
|
Output |
2 TV, BNC(1.0V p-p, 75Ω), 1 VGA, 1 HDMI(Optional) |
|
|
Standard |
PAL / NTSC |
|
|
VideoLoop |
16CH |
|
|
Audio |
Input |
16CH, RCA(200-2800mV,30KΩ) |
|
Output |
2CH, RCA(200-3000mV,5KΩ) |
|
|
Voice intercom |
||
|
Display |
Display split |
1 / 4 / 8 / 9 / 16 |
|
Resolution |
1440*900, 1280*1024,1280*720， 1024*768, 800*600 |
|
|
Tour display |
Support |
|
|
OSD |
Camera title, time, video loss, camera block, motion detection, recording |
|
|
Record |
Video/Audio compression |
H.264/G711 |
|
Image resolution |
960H/D1(704 * 576/704 * 480), HD1(704 * 288/704 * 240), CIF(352 * 288/352 * 240) |
|
|
Encoding speed |
Main stream: CH1~16 D1(1~25/30FPS) |
|
|
Extra stream: CIF(1~25/30FPS),QCIF(1~25/30fps) |
||
|
Image quality |
1~6 level (level 6 is the best),VBR effectively |
|
|
Record mode |
Manual, schedule(always, motion detection, video lost, video blind, alarm), stop |
|
|
Record sequence |
Manual>Alarm>Motion detection>General |
|
|
Alarm |
Triggering event |
Record, Snapshot, Alarm, Email |
|
Motion detection |
Area: 396(22 * 18), Sensitivity: 1-6 level |
|
|
Video loss |
Support |
|
|
Alarm input |
16CH |
|
|
Alarm output |
4CH |
|
|
Playback and backup |
Playback channel |
1 / 4 / 8 / 16 |
|
Playback speed |
960H 100/120FPS |
|
|
Search mode |
Time/Date, Alarm, Motion detection Exact search(accurate to second) |
|
|
Playback function |
Play, Pause, Stop, Fast play, Slow play, full screen, backup |
|
|
Back mode |
Flash drive/USB HDD/CD-DVD RW/Network download |
|
|
Network |
Interface |
RJ-45 port(10/100M) |
|
Network functions |
TCP/IP,UDP,DHCP,DNS,IPFilter,PPPOE,DDNS,FTP,Email,UPNP,Alarm Server ARSP |
|
|
Remote operation |
Monitor, PTZ control, Playback, System setting, File download, Log information |
|
|
Hard disk |
Interface |
8 SATA Ports, each port support max 24TB HDD or 1 DVD-RW |
|
management |
Hard disk standby technology, hard disk failure alarm |
|
|
Auxiliary interface |
USB Ports |
2 USB Ports: 1 for mouse control, 1 for backup |
|
RS485 |
PTZ Control |
|
|
Environment |
Power supply |
DC 12V,6A |
|
Environment |
-10℃ ~+55℃ /10~90%RH/86~106kpa |
|
|
Dimension |
2U, 510mm * 490mm * 180mm |
|
|
Weight |
8.7KG(without HDD) |
